MFU-2130P Portable Filtration System

High Performance Filtration for Today's Industry

1800 GPH


  • Heavy duty 2 HP TEFC 230 volt single phase Baldor motor with Thermal Overload Protection
  • 30 GPM positive displacement mechanical seal gear pump with internal relief valve
  • One (1) polyurethane powder baked high flow element housing
  • Wired 230 Volt, 1 phase with all electrical components mounted in a NEMA 4 enclosure
  • Manufactured with automatic high pressure shutdown system for unattended operation
  • Motor starter with on/off toggle switch
  • Plumbed with all brass and black iron fittings
  • 1 1/2" inlet and outlet ports with cam loc fittings
  • Fifteen (15) feet of heavy duty 12/3 power cord
  • Manufactured with 3-way ball valves for fluid fransfer system
  • Suction-Wye Strainer to protect pump from large debris
  • 0-100 PSI glycerin filled gauge for monitoring system pressure
  • Inline brass re-settable flow totalizer
  • Heavy duty 12" pneumatic tires
  • Filtration capacity of 27 GPM and fluid transfer capacity of 30 GPM

*Available in 110 VAC


Hydrolic Oil • Compressor Oil • Quench Oil • EDM Oil • Lubricating Oil • Insulating Oil • Turbine Oil
